Steel Mezzanines

  • Easy Assembly
  • Cost-effective
  • Flexibility and Scalability
  • Save time
Request Our Latest Price

What is Steel Mezzanines

Steel mezzanines offer cost-effective solutions to expand your floor space without extensive construction. Using pallet racking as the core framework, we create versatile mezzanine structures for various load-bearing needs.

Each level typically supports up to 500kg, with floor panels bearing 300kg to 1000kg per square meter. The distance between levels ranges from 2.5m to 3m, while top-level pallet racking reaches approximately 2 meters in height, ensuring convenience for personnel and machinery operations. This maximizes your existing storage capacity, saving you costs on labor, land permits, leases, or additional construction materials.

Read More

OKE Storage's Steel Mezzanines

Warehouse Mezzanine
Warehouse Mezzanine
Industrial Mezzanine
Industrial Mezzanine
Steel Mezzanine
Steel Mezzanine

Manufacturing Process

Product Details

Mezzanine Flooring
Mezzanine Flooring
Safety Lock
Safety Lock
Flooring Option
Flooring Option
Stair
Stair
Stair Connect
Stair Connect
Railing
Railing
Strong Upright Frame
Strong Upright Frame
Main Beam and Top Bracing
Main Beam and Top Bracing
Bolted BasePlate
Bolted BasePlate

Benefits of Steel Mezzanines

  • Sturdy, multi-level design
  • Non-welded, adjustable assembly
  • Complies with OSHA, BOCA, and UBC
  • Quick to clean and assemble
  • Available in various sizes and floor types
  • Enhances material flow
  • One-time investment
  • Meets seismic zone requirements
  • Adds extra square footage
  • Accommodates conveyor systems, heavy-duty equipment, and machinery.
Send Inquiry Now1
Benefits of Steel Mezzanines
Components of Steel Mezzanines

Components of Steel Mezzanines

Upright: provides support and bear loads and is made of high-quality Q235 cold-rolled steel, formed through bending and punching.
Beam: High-quality cold-rolled steel is used to connect the columns and create space for storing goods. The height of the beams can be adjusted accordingly, based on the hole distances on the columns, which are typically set at 50mm or 75mm.
Flooring: Strong load-bearing checkered steel plates or perforated plates are used to connect two bays of the shelving, providing walkways for manual access to goods.
Shelf Board: installed on the beams of the shelving to support goods. Each shelf can bear a maximum load of 500kg.
Back Net: Typically installed at the rear of the upper shelving to prevent goods from falling and reduce the risk of personnel being struck by falling items.
Guardrail: Installed around the perimeter of the upper shelving, with three guardrails on each side, significantly enhancing the safety of personnel.
Staircase: Comprising of step boards and handrails, it is bolted securely onto the floor panel, facilitating the movement of personnel up and down the Steel mezzanines.
Unloading Port: Usually positioned at the guardrail locations, facilitating the access of forklifts to heavy goods.

Send Inquiry Now2

Working Principle of Steel Mezzanines

A steel mezzanine is a platform that is positioned between the main floor and ceiling of your factory. Also, it does not take up a huge space in your warehouse or factory. Therefore, once the structure is erect, it makes a new flooring level. As a result of this newly-created vertical space, you get the opportunity to store more stock in a less messy and more organized way.

Send Inquiry Now
Working Principle of Steel Mezzanines

Safety Consideration - Steel Mezzanines

Safety consideration - Steel Mezzanines1
Safety consideration - Steel Mezzanines2

Steel mezzanines play a key role in ensuring your workers’ safety, and their correct installation can prevent numerous mishaps, such as accidental falls. OKE Storage pays close attention to manufacturing structures that are safe for your workforce. Our mezzanines comply with OSHA and IBC building codes.

To comprehensively ensure the safety and stability of our mezzanine shelving systems and to provide you with confidence and convenience when using our shelving, we have deliberately incorporated the following safety accessories into the shelving design:
Flooring:
Hole Patterns: Available in Type II elongated holes and circular holes. Hole design complies with fire safety requirements of all countries.
Self-Drilling Bolts and Safety Latches: High-quality Self-Drilling Bolts and reinforced safety latches enhance the connection between the floor panels and angle steel, reducing any shaking at the joints. These multiple safeguards ensure a more secure connection of the floor panels.
Staircases:
Reinforced and Thickened Non-slip Tread Plates: Featuring thicker anti-slip tread plates and elevated handrails on both sides to prevent personnel from slipping or stepping into empty spaces, ensuring a confident and safe usage experience.
Back Nets:
Thickened Wire and Enhanced Hole Design: Designed with thicker wires and denser holes to prevent smaller-sized items from falling through, guaranteeing the safety of your personnel.
Aisle Braces:
Aisle braces are installed beneath every aisle, reinforcing the aisles and ensuring the overall stability of the mezzanine shelving system.
Guardrails:
Three Thickened Guardrails on Each Side: Each side is equipped with three sturdy guardrails (1.5mm thick) to ensure the safety of personnel.
Loading Ports:
Equipped with double doors for easy access by forklifts and to ensure the safety of operators.
Edge Seals:
Positioned at the bottom of the floor panels and guardrails to prevent goods from rolling off the floor panels, further ensuring the safety of personnel.

Steel Mezzanines Powder Coating

Steel Mezzanines Powder Coating 1
Steel Mezzanines Powder Coating 2

Production Parameters

Stair Options1 or 2, customizable
Mezzanine Levels2-3 levels
Height2.5m~3m, customizable
Uprights60×50×1.5mm，70*50*1.5m or 90×70×2.0mm，customizable
Beams50×30、64×40、80×50，customizable
Load CapacityMax 500kg per level
Shelf DeckingFlat steel plate, checkered steel plate, perforated steel plate
Flooring MaterialCheckered steel plate or perforated plate
Flooring Hole TypeType II elongated holes, circular holes

Customized Mezzanine Systems with OKE Storage

OKE Storage makes custom steel mezzanine tailored to your needs. With customized heights, dimensions, spans, railing, and flooring, we ensure that we provide the best solutions. Regardless of your requirements, we can build simple to complicated multi-level mezzanines. Our bolted steel design is quick to install at your warehouse. Also, our experts are always ready to design the best mezzanine system according to your facility’s whereabouts.

1. Mezzanine Floor Design Drawing

2. Customized Color

Steel Mezzanines Customized Color

3. Customized Upright Holes

Why OKE Storage Reliable and Trusted?

  • Strictly Racking Quality Inspection
  • Packaging
  • Shipping
  • Successful Cases

Our engineers are well-qualified and well-skilled and continuously inspect and test all customized mezzanines before delivering them to you.

Successful Case1 Successful Case2 Successful Case3 Successful Case4 Successful Case5 Successful Case6

  • “Our warehouse was chaotic and disorganized until we contacted OKE Storage. This company designed the best steel mezzanine for us, which expanded our workings pace.”

  • “When our storage requirements grew, someone recommended OKE Storage as a solution. They not only provided a great mezzanine but also customized it according to our needs. Thanks for saving us from a huge mess. “

  • “As a manager of a freezing unit in the US, our company was running out of space. But OKE Storage designed and delivered a powerful steel mezzanine system for us, and now we can keep goods at different temperature levels. “

Steel Mezzanines Material

Steel Mezzanines material

Load Capacity Test and SGS Report
Detailed Quality Control

Steel Mezzanines Detailed quality control 1           Steel Mezzanines Detailed quality control 2

Production Process

Steel Mezzanines Production Process

Steel Mezzanines Advanced Production Equipment

Steel Mezzanines Advanced Production Equipment

Related Product

FAQ

How do you support a mezzanine in the best way?

Using accessories to support a mezzanine are C-sections, girder joists, beams, and bar joists. These three are the best mezzanine frames you should consider.

Is the slab good enough to support a mezzanine?

We can assist your engineer in figuring out whether your current slab is capable of supporting your mezzanine or if you will need new footings.

What is the minimum clear height for a steel mezzanine?

The ideal and minimum clear height from the mezzanine to the ceiling and below the mezzanine to the primary floor should be at least 7ft.

What different varieties of steel are used in steel mezzanines?

When opting for steel mezzanines, you will generally find three variations in the quality of steel.

1. Cold-Rolled Steel Mezzanines
These are lightweight mezzanines compared to structural solutions. However, the lightweight does not mean they have a weak load-bearing or storage capacity. The cold-rolled mezzanines come with a smoother finish, which is best for stock monitoring.
2. Structural Steel Mezzanines
Structural steel mezzanine is the most cost-friendly type and generally heavier than the other solutions. What makes the structural mezzanine different is the use of tubular and joint columns with I-beams for ideal support.
3. Stainless Steel Mezzanines
If you’re looking for a corrosion-resistant solution, you can choose the steel structure mezzanine. These mezzanines are widely used in food processing facilities and are highly expensive.

Which floor types are available for steel mezzanine
  • Bar Grating Decking: Perfect for facilities that adhere to stringent guidelines for lighting, ventilation, and fire safety. ·
  • Diamond Plate Decking: An enduring choice for mezzanine flooring, often utilized for mezzanine entrances. ·
  • B Decking: Also known as corrugated steel and roof decks, these are constructed from robust yet lightweight materials, making them a common choice for mezzanine sub-flooring.
  • Plywood Decking: If you want smooth flooring to move your wheeled machinery and pallet jacks on the mezzanine flooring, then plywood decking is a great reasonable option.
  • Metal Plank Decking: Constructed from galvanized materials, the metal plank decks are mostly utilized for outdoor facilities or mezzanines that store wet or frozen items. This deck allows the passage of air, light, and water.
Process of Acquiring Your Steel Structure Mezzanine from OKE Storage
  • Step 1: Customer Support for Free Consultation
  • Step 2: Information and Quote
  • Step 3: Layout Approval
  • Step 4: Manufacturing and Delivery
  • Step 5: Installation
What should be considered when using mezzanine shelving?

Avoid Overloading: Each mezzanine shelving unit has a maximum load capacity, and it is crucial to avoid exceeding this limit to ensure the safety of the mezzanine shelving system.

Evenly Distribute Goods: Whenever possible, distribute goods evenly throughout the entire area of the shelving. Heavier items should be placed on lower levels, while lighter items can be placed on higher levels. This prevents the center of gravity from shifting upward, thereby enhancing the overall safety of the shelving.

Regular Inspection: Regularly inspect the shelving for loose or missing components and address any issues promptly.

Fire Safety: Ensure that the shelving does not obstruct fire evacuation routes. Additionally, consider the combustibility of stored goods and choose appropriate fire-resistant materials or coatings.

Do you have quality certifications?

All our products undergo quality monitoring and inspections at each stage of the production process. We use CNC punching and shearing machines for material processing to ensure dimensional accuracy and product quality. Our production process includes intelligent welding and surface treatments such as shot blasting, rust removal, phosphating, cleaning, and powder coating, with a layer thickness of up to 60-80 micrometers, ensuring high quality. We hold ISO9001 certification, environmental system certification, health system certification, and CE certification.

How soon can I receive the shelving?

On average, it takes about 20-25 days. Customized products may require more time.

What warranty or support do you provide for mezzanine shelving?

Depending on your requirements, we offer a one-stop service that includes free consultation, free design drawings, free samples, comprehensive installation services, and professional after-sales support (10-year warranty).

Can I install mezzanine shelving myself?

You can install it following our installation instructions, but we recommend having professional assistance and guidance to ensure a smooth and safe installation process. If needed, we also offer installation services.

What types of goods are suitable for mezzanine shelving?

Mezzanine shelving is suitable for lightweight items with a large storage volume. Examples include automotive parts, light industrial products, electronics, machinery and hardware, pharmaceuticals, clothing, plastic products, and more.

What is the importance of a stairway in metal mezzanine systems?

Metal stairways give you easy access to your mezzanine system. Depending on your floor distance, you can install mezzanine stairs in 8 to 15 steps and even more. OKE Storage designs high-quality stairways that meet BOCA, IBC, and OSHA safety regulations. Our company uses the “mill first” steel to manufacture staircases under the supervision of expert engineers and qualified welders. Our stairways have the following traits:

  • KD bolted design
  • 8-inch stair stringers
  • 1.5 inches of welded handrails
  • Diamond-plated 11-inch stair treads and closed risers
  • 36-inch handrails and 42-inch guardrails adhering to IBC standards
