Very Narrow Aisle Pallet Racking Manufacturer and Supplier in China

Key Features of Very Narrow Aisle Pallet Racking:

  • Easily compatible with automated racking systems
  • Directly accessible to all pallet loads with 100% selectivity
  • Highly controlled racking system
  • Flexible in terms of design

What is Very Narrow Aisle Pallet Racking

The very narrow aisle racking system is the strongest racking solution. It tightly holds pallets, has a high tolerance, and maintains sturdy connections.

Similar to standard selective racking types VNA racking has an edge in increasing storage capacity by reducing aisles as per need. And pallets can be handled with the help of special types of lifting trucks/side loading forklifts.

The product picking rate is high with advanced vehicles or VNA trucks. An automated guidance system has been designed with narrow aisle racking.

narrow aisle pallet racking system efficiently utilizes the storage space and saves even an inch of square footage. It may increase the storage capacity by up to 50%.

Read More

Very Narrow Aisle Pallet Racking Benefits

Easy Installation
Easy Installation

Easy to install or implement

Visibility
Visibility

High visibility of products

Flexibility
Flexibility

Flexible in terms of design

Strong capacity
Strong capacity

Increase the storage capacity of your warehouse

Very Narrow Aisle Pallet Racking Advantages

Very narrow aisle pallet racking enhances the storage space of your warehouse smartly with the great usability of floor space. Its flat floors are designed in such a way that you can adjust heavy loads safely.
narrow aisle racking would be the best option when need to optimize your working area by reducing aisle space.
Advantages:

  • Convenient stock rotation
  • Fast throughput
  • Very low labor costs may be required
  • Inexpensive installation cost
  • Use FIFO (First-In First-Out) cycle
  • Make good use of height space
  • Economical storage system
  • Easily compatible with automated racking systems
  • Directly accessible to all pallet loads with 100% selectivity
  • Highly controlled racking system
Very Narrow Aisle Pallet Racking Advantages
Working Principle of Very Narrow Aisle Pallet Racking

Working Principle of Very Narrow Aisle Pallet Racking

As the name very narrow aisle/VNA describes, the space between the aisle is very small. Pallet loads can be accessed with the help of lift forklifts.

The operations can be done by an automatically designed system. An automated guided vehicle that can be directed and moved safely within the warehouse.

In very narrow aisle pallet racking, for lifting loads from pallets or order picking goods, a special type of equipment has been used as per needs.

This system is easy to install, decreases accidental damage risk, and reduces working labor as well.

Our Safety Measures

Our Safety Measures1
Our Safety Measures2

In VNA pallet racking the main factor that we must be taken into consideration is automatic guidance vehicles. A special type of forklift is required for this system.
Other than that we need to focus on metal rails, roller guides, and automated wired guidance system checking. Some special components help in safety measures. We must take essential measures while installing VNA racking.

Guard rail
The specification is 100*63*6.0. Triangular reinforcements are added every 500mm to make the guard rail stronger.
Guard rail corners
Set up denser and thicker triangular reinforcements to Strengthen the anti-collision performance of Guard rail
Pallet backstop Types
The backstop of the pallet rack is made of metal and secured with bolted arms, as well as uprights or columns.It is used to prevent pallets from falling. It makes loading and unloading more secure.
Backstop for floor pallets
As the name described, this component is fixed to the floor. It manages floor-level pallets either with single or double backstops as per requirement.
Safety Bolt
7-shaped, inserted into the holes of the uprights to maintain the stability of the beams.
Back Mesh
Installed on the sides of the shelves to prevent small items from scattering..
Goods Dividers
Used to separate goods to prevent them from tilting or collapsing when stacked.
Pallet Supports
Increase beam support and prevent items from falling, available in two types: single- and double-sided.
Diagonal Braces
Support structures between shelf uprights that increase the overall stability of the shelves, reducing lateral deformation and shaking.
Cross Braces
These connectors can be installed between the horizontal beams of the shelves to increase overall rigidity.
Row spacer
Maintains stability between mainframes and sub-frames.
Shims
Provide shock absorption, reduce noise, adjust shelf height and horizontal angles, and prevent shelf sliding.
Markers
The markers are used for guidance. A rectangular metal plate that gives information about signs. These signs may place on outer areas of narrow pallet racking at different aisle points.
Warning of Loading Notices
The load warning notice may be applied on prominent and visible places of VNA pallet racking.
The load warning notice may include the following information:

  • The safety notices
  • Type of racking system
  • Load bearing installations
  • Manufacturer’s contact information

Label about carrying a load
Its purpose is to mention the load capacity of beams VNA racking. It reduces the damage risks in your warehouse.You may overcome loading and unloading mistakes.

Quality Assurance

Quality Assurance1
Quality Assurance2

OKE Storage ensures the safety and quality of the VNA racking system by following international quality standards.
10 Years Super Long Warranty
Your satisfaction is our priority! OKE Storage gives a super long warranty of 10 years over its racking systems.
Inspection of components
Our quality inspection performs strict quality tests of each component at all phases from design to manufacturing and manufacturing to implementation.
Fully Advanced Manufacturing
OKE Storage uses the latest technology and advanced equipment in the manufacturing of VNA pallet racking. Our automated machinery includes steel panels, laser cutting, automatic welding, heavy-duty punch machine, eyelet machine, Steel Plate Shearer, etc.
Highly Customized Designs
Our experts will submit a Free sample solution 1:1 3D before bulk production or initial phases. Our design services may include, 3D sampling, logo at racking surface, face design options, and other customized options available.
Quality Certifications
OKE Storage has passed quality certificates of CE and ISO that are known internationally.
Comply with the following:

  • AS4084 Standard
  • RMI Standard
  • FEM Standard
  • ISO 9001: 2015

The Reasons Why You Choose VNA racking From OKE Storage

The Reasons Why You Choose VNA racking From OKE Storage1
The Reasons Why You Choose VNA racking From OKE Storage2

Here you will get a complete package of services which may include designing, manufacturing, installation, and full-fledged guidance even after the implementation of your VNA pallet racking project.

OKE Storage has an exceptional experience of 20+ years in manufacturing of high-class racking products.

Our experts noted your set of instructions and manipulated the system according to that. The very narrow aisle racking system fully fits your storage needs.

To achieve damage-free shipments, OKE Storage experts ensure the safety of the package by using a steel fixation belt, covered with conventional wrapping film along with airbags between packages.

In making of VNA racking system, OKE Storage uses only top-quality raw materials with top-notch-quality steel from China’s reputed steel company (Bao Steel Co, Ltd.)

You will get fast and lightning delivery for a narrow aisle racking system

as committed by the OKE Storage logistic team. Our standard delivery time is 10-15 days of working days. Our passionate loading team can handle 12*40HQ containers in one day.

OKE Storage after-sales services are on the go! Our customer support team is always ready to assist you. You can contact us round the clock 24/7.

Difference Between Standard Selective Racking and Selective VNA Racking

Standard Selective Racking
  • Standard selective racking can support a lesser amount of pallet positions than VNA racking
  • Decrease the number of rows than VNA racking
  • Less forklift required
  • Low-density storage than VNA racking layout
  • Follows the FIFO system
Selective VNA Racking
Selective VNA Racking
  • VNA racking can have more pallet positions than standard selective racking
  • More expensive because of costly equipment and technology
  • Special kinds of forklifts required
  • It prevents accidental damage
  • Very low labor cost
  • High-density storage system

Very Narrow Aisle Pallet Racking Key Applications

VNA Racking applications of Pharmaceutical Chemical

Pharmaceutical Chemical

Medical companies have high demands to keep their products. Need to maintain special temperatures, manage expiry dates, need fast stock rotation. VNA pallet racking perfectly fits here.

VNA Racking Application of Warehousing & 3PL

Warehousing and 3PL

The maximum operations are controlled by Automated Guided Vehicles, reducing product damage. OKE Storage suggests narrow racking to Logistics companies.

VNA Racking Application of E-Commerce

E-commerce

All online businesses prefer efficient storage systems that speed up their working tasks. With advanced order picking and side lifting vehicles they prefer VNA racking.

VNA Racking applications of Food and Beverage Industry

Food and Beverages

A very narrow aisle racking system is an ideal solution where you need easy and fast stock rotation. The food and beverages industries go for this type of racking system.

Very Narrow Aisle Pallet Racking Manufacturer
Very Narrow Aisle Pallet Racking Manufacturer

Very Narrow Aisle Racking can increase the storage capacity of your warehouse, As an experienced manufacturer, We can offer you professional guidance if you need it.

Why OKE Storage Very Narrow Aisle Pallet Racking Reliable?

Aisle Selection Single Row, back-to-back Rows, and multiple Rows
Beam Height: 80~160mm; Width: 50mm; Thickness: 2.0-2.5mm
Upright 80*60; 90*60; 90*70; 90*75; 100*67; 100*70; 100*75; 120*95mm, Thickness: 1.5~3.0mm
Load Capacity 5000kg (each shelf )
Shelf Height Adjustment 75/50mm
Depth 850-1050mm Or Customized
Width 1800/2700/3600mm Or Customized
Height Max 12000mm Or Customized
Color Blue(RAL5005/5015), Orange(RAL2004)or Customized: All RAL Color, MOQ( per 20FT container)
Delivery Time 15-20 days for one container
Product Details
Model Number Very Narrow Aisle Pallet Racking
Assembly Required Yes
Brand Name OKE Storage
Beam Type Step Beam/Box Beam
Construction Type Bolted Frame
Type Starter
Number Of Levels According To Customer Needs
Material Steel/Q 235B Steel(Same Level SS400), Q345 Steel( Same Level SM490)
Unit Bay Capacity 500kg – 23000kg / Customized
Surface Finish Powder Coated/ Galvanized
Packing Package Ends With Cardboard And Bundle With Steel Strapped Outsides, Follow The Customer’s Needs.
Feature Durable, Corrosion Protection
Use Warehouse Rack
Usage Warehouse Storage System
Application Widely Used
HS Code 73089000
Products Support
Free Consultation Yes, Any Questions You Can Consult With Free.
Support For Custom Yes
Free Design Yes, CAD/PDF/3D Drawing
Free Sample Available (Delivery Cost By Buyer)
3D Sample Yes, 1:1 3D Sample, Save Your Time And Cost of Trial and Error
Pre-installation Yes
Capacity Test Yes, If Needed.
OEM&ODM Available
Certification CE / ISO
Lead Time 15-20 Days For Regular Pallet Racking, One Container
Installation Service Yes, Submit the Installation Drawing Or Video, and send the Engineer To Your Site If Needed.
Maintenance Service Yes, We Submit a Free Maintenance Guide.
Repair Service Yes, We Submit Repair Services.
